Wilmad
Precision NMR Tubes
Wilmad O.D. Thin Walled Precision NMR
Tubes
Wilmad -
LabGlass 는 80년의 역사를 가진, NMR Tube를 처음 제조하고 발명한 회사입니다.
Frequency(MHz
Rating)의 기준을 정격한 미국 브랜드로, 튜브의
직경오차가 작아 정밀성이 매우 뛰어납니다.
(주)비케이인스트루먼트는 미국
Wilmad- LabGlass사의 공식대리점으로 보다 합리적인 가격에 다양한 제품을 취급하고 있습니다.
To maximize SNR,
Precision NMR Tubes have minimal paramagnetic impurities that would impact
shimming. Tight I.D. and O.D. tolerances as small as 0.0065mm accommodate
Wilmad inserts.
• Manufactured in
a state-of-the-art ISO 9001:2015 USA facility using a unique precision
shrinking and grinding process to shape the inner surface with maximized
filling factor
• Inner surface is
resistant to strong acid and base at ambient temperature
• Can be operated
safely at temperatures up to 230˚ C, and within a temperature step of 120˚
C
• Rated as
hydrolytic class 1
• Ideal for
experiments requiring critical shimming quality (high/ultrahigh field,
multi-dimensional, multi-nuclei, DNP experiments and studies involving
biological samples)
• Made from
borosilicate glass that meets the requirement of Type 1 Class A glass from
ASTM E438
• 100% inspection
with multiple NIST traceable gauges and optical surface defect checks
• Includes
disposable cap
Note: Caps are not recommended
for use with samples dissolved in chloroform-d or acetone-d₆.
